Elephant® e-MY Lite – Technical specifications

Elephant® e-MY Lite - Technical specifications

Chassis:

• Model Vestergaard e-2070 or 20140
• Maximum speed limited to 30 km/h.
• Hydraulic brake system 2 circuit
• Wheelbase is 4200 mm.
• Comfort package with heating and air conditioning
• Spring activated parking brake with hydraulic release.
• Enclosed cabin with side doors in safety glass, including wipers and washer on front window
• Electrically heated and adjustable rear-view mirrors
• Comfort package includes Insulation of cabin, Noise reduction of cabin
• Power steering
• Fully adjustable steering column
• Driver’s seat with air suspension, and 3 points seat belts
• Fixed instructor seat
• Advanced HMI display showing all relevant information for the chassis.
• Site-manager for online access from Vestergaard
• 12 V, 5 A power supply for VHF radio in cabin, and USB charger in cabin
• Front tires 385/55 R22.5
• Rear tires 315/70 R22.5
• NOTE: NOT APPROVED FOR ROAD REGISTRATION

Electrical system:

• Battery lithium-ion type800 V, Standard 70 kWh, option 140 kWh battery,
• 22 kWh onboard charger.
• Charge inlet: Type 2
• Driveline: 110 kW electrical motor

Colour scheme:

• Chassis cabin and tank section: White colour (RAL9016)
• Boom system: Light grey colour (RAL7040)

Tanks:

• Tank capacity: 7.600 liters. 5.600 liters for Pre-mix Type I. And 2.000 liters for Type II/IV
• Tank 1 is thermally insulated from tank 2
• Digital level indicator in cabin, including automatic “low level shut off”
• Removable cover plate for inspection of tanks
• Stainless steel, 5 years warranty.

Heating system:

Either:

• Diesel heating 230 kW capacity, with automatic batch heating system to ensure a quick start-up. And automatic fire extinguishing system

Or:

• Electric heating available max 36 kW

Lift system – performance

• Maximum nozzle height 14,5 m.
• Basket floor height 13 m.
• Horizontal reach 10 m (@ 5 m level)
• Boom rotation +/- 150 degrees
• Rated load in cabin: 205 kg
• Fully proportional operation of boom system
• Open basket design
• Rated load in basket: 205 kg

Safety:

• Camera solution as skylight view
• 2 LED lamps on basket for proper illumination of working area and illuminated of operators panel in basket
• Emergency lowering in basket

Main options

• One man: allows unit to be operated from basket
• Rear view camera
• Top level sensor for bottom filling
• Extra Tank level gauges on side of tank
• Ground gun: 15m 3/4″ hose reel with 1″ handgun, left side
• Hot At Nozzle.
• Amber flashing beacon
• Easy access into tanks via manhole covers
• Collision sensors mounted on all 4 corners of the basket

Fluid System:

• Separate tubing of Water/Type I mix and Type II/IV fluid all way to spray nozzle
• Pump Tank 1: Centrifugal Type-I compatible max. flow rate 230 l/min.
• Pump Tank 2: Diaphragm Type-II-IV compatible, max. flow rate 100 l/min
• Connections for bottom filling and dumping, located on the left side.
• Display in chassis cabin showing tank 1 and batch tank temperature, and fluid level in tank 1 and 2

• Standard one spray gun in basket, second is optional
• Indicator in operator’s basket for spraying temperature of tank 1.
• All fluid connections are 2″ threaded for easy fitting of couplings.
• Tank one has an internally mixing function for onboard premixing

Norm compliance

• European Machinery Directive 2006/42/EC – CE
• EN1915 1-2-3-4
• EN12312-6

Dimensions

• Length 3 meters
• Width 2,5 meters
• Height 8 meters
